|Deep Color / x.v. Color Support||Yes (36-bit) / Yes, on three of the seven HDMI inputs|
|3D Support||Yes, on three of the seven HDMI inputs|
|Upscaling||From 1080p to near-4K on three of the seven HDMI inputs|
|Pass-Through||Up to 4K/60p with HDCP 2.2 on three of the seven HDMI inputs|
|Power Output||120 W per channel @ 8 Ohms, 1 kHz, 0.08% THD, 2-channel driven FTC200 W per channel @ 4 Ohms, 1 kHz, 1% THD, 2-channel driven560 W total @ 8 Ohms, 1 kHz, 1% THD, multi-channel|
|Amplifier Type||Class D³ (Direct Energy HD)|
|Weight||26 lb (11.8 kg)|
|Graphical User Interface||Yes|
|Power Requirements||120 VAC, 60 Hz|
|Power Consumption||Active: 250 WStandby: 0.15 W|
|Dimensions (W x H x D)||17.1 x 7.3 x 15.6" (435 x 185 x 395 mm)|
|Bluetooth||YesVersion: 4.1Profile: A2DP, AVRCPCodec: SBC, AAC|
|Streaming Capability||Google Cast, with a future firmware updateTuneIn, with a future firmware updateSpotifyTidal, with a future firmware updateDeezer, with a future firmware update|
|Input||7 x HDMI (1 front), three of which support HDCP 2.21 x Component video2 x Composite video1 x USB (front)4 x Stereo RCA1 x Stereo RCA phono2 x Optical TOSLINK1 x Digital coaxial|
|Output||2 x HDMI 1 x 1/4" (6.35 mm) Headphone (front)|
|Other Ports||1 x Ethernet1 x Zone 2 pre-out2 x Subwoofer pre-outs1 x Calibration microphone (front)1 x AM antenna1 x FM antenna1 x Ground1 x RS-232C in1 x IR in1 x IR out2 x 12 V trigger outs1 x Power cord|
|Speaker Connectors||9 x Binding post pairs|
|A/B Speaker Selection||Yes|
|ARC (Audio Return Channel)||Yes|
|Wi-Fi||Yes, dual-band 2.4 / 5 GHz|
|File Support||Via USB: MP3, WMA, AAC, Apple Lossless, WAV, FLAC, AIFF, DSD|
|Digital-to-Analog Converter (DAC)||AK4458 384 kHz / 32-Bit|
|DSP||1 x Cirrus Logic Quad Core|
|Formats Supported||Native: Dolby Atmos, Dolby Surround, Dolby TrueHD, Dolby Digital Plus, DTS-HD Master Audio, DTS-HD High Resolution Audio, DTS 96/24, DTS-ES, DTS-HD ExpressWith Future Firmware Upgrade: DTS:X, DTS Neo:X, DTS Neural:X|
|High-Resolution Audio Format||Apple Lossless, WAV, FLAC, and AIFF for 192 kHz/24-bit11.2 MHz / 5.6 MHz / 2.8 MHz DSD playback via USB or wired networkDolby TrueHD Playback via USB only|
Well it's kind of funny how I came across this receiver. My vsx-lx 301 amp blew after 2 months. Just right around that time I was also doing research on the different amps. My original receiver had a class D amp. and the 501 had a D3 amp.
d3 Amp, Clarity, separation features 3 year warranty on parts and labor
doesn't have satellite radio (not a deal breaker)
I chose to "upgrade" to the SC-LX501 as it has HDCP 2.2 compliant ports (although not all of them) The menu system was nice but the fine setup of ports and audio setting just wasn't there.
Having recently purchased an Oled B6 it was time to upgrade my old Sony DA2400ES. Having conducted all the usual research it was either the Denon AVR-X2300W Or the 501!! Needless to say I went for the more expensive unit and have not been disappointed thus far.
My Onkyo Receiver bit the dust today and needed replacing. I had heard good things about the Pioneer SC-LX501 and decided to give it a go. On unboxing the amp I was pleased to find that it was very intuitive to set up, the SC-LX501 comes with all the ports you could possibly need and a few more for...
feature packed, intuitive setup, great sound
cheap plastic dials
